Eastwood Elite Panel Metal Cutting Air Powered Saw with Diamond Blade

The Eastwood Elite Panel Cutting Saw is designed for creating extremely high accurate cuts in metal on the inside or outside of your scribe line.

• Powerful Heavy-Duty .5 Horsepower Motor
• Operates with Only 4 CFM at 90 PSI
• Engineered for Optimum Performance with the use of a Diamond Blade
• Reversed Blade Direction Creates Clamping Action for Precise Tracking
• Straight, Plunge, and Scroll Cuts All in One Tool
• Handle Rotates 120 Degrees Around Base for Cutting in Tight Areas
• Micro Adjustable Guard and Innovative Sight Lines for Precise Cuts

Integral Guard/Base Assembly - The heavy-duty die-cast blade guard integrates a unique indexed handle rotation system, allowing for the handle to rotate around the base up to 120°. This adjustment allows for access in areas where a standard fixed-handle metal saw cannot reach.

Inside-Outside Sight Line - The aluminum base plate is precision laser-etched with blade alignment marks to allow the user to make accurate cuts on the inside or outside of a scribe line. The Panel Saw is also easily capable of starting with a plunge cut, making a scroll cut, or cutting through multi-layered panels.

Quick-set depth gauge - Allows user to accurately set blade depth to cut just top panel not damaging lower panel for repair.

Panel Saw Specifications

Air Consumption: 4 CFM
Operating Air Pressure: 90 psi
Free Speed: 17,000 RPM
Horsepower: 0.5
Maximum Cutting Depth: 1/4" (6.3mm)
Cutting Wheel Size: 3" (Included)
Arbor Size: 3/8" (9.5mm)
Air Inlet: 1/4" FNPT
Housing Construction: Aluminum with Cushion Grip
Wheel Guard Construction: Aluminum Die Cast
Base Plate: 5/32" (4mm) Steel with Laser Etched Guide Marks
Spark Guard Construction: Steel
Speed Adjustment: Lever Type on Housing
Trigger Type: Paddle with Safety
Exhaust: Rear

Diamond Blade Specifications

Diameter: 3"
Thickness: 0.05"
Arbor Size: 3/8"
Maximum RPM: 20,300
